Cylindrical magnet h6 machinable type VS 07
print
REF 92.07
  • 92-07

Cylindrical magnet h6 machinable type VS 07

    • Samarium magnet
    • High holding power
    • Heavy duty construction
    • Long service life
    • Effective

  • Use :
    • Mounting
    • Clamping
    • Assembly
  • Max. temperature of use :
    • 200 °C
92-07-442

Qty Product Weight in kg A B C D
92.07-60.0046h620108 N
92.07-80.0088h6201022 N
92.07-100.01210h620840 N
92.07-130.02013h620660 N
92.07-160.03016h6202125 N
92.07-200.06020h6255250 N
92.07-250.13425h6357400 N
92.07-320.25132h6404.5600 N
indication_tableau_dessus
